Multifunctional Orthopedic Power System
The Multifunctional Orthopedic Power System is a modular, high-performance surgical power platform intended for orthopedic, trauma, spine, and neurosurgical procedures. The system accomplishes various tasks like drilling, sawing, milling, craniotomy, and K-wire insertion simply by combining one multifunctional host with multiple interchangeable attachments, thus meeting a broad spectrum of surgical needs with only one power source.
This system is used for:
Bone drilling for fracture fixation and implant placement
Bone cutting and shaping during orthopedic and trauma surgery
Sternotomy and thoracic procedures
Craniotomy drilling and milling in neurosurgery
Kirschner wire insertion for temporary or definitive fixation
One host, multiple surgical applications, reducing equipment changes and operating time.
Specification
| Item | Specification |
|---|---|
| Product Name | Multifunctional Orthopedic Power System |
| Series | N Series |
| Model | JM81011000 |
| Speed / Frequency | 0–18,000 times/min |
| Functions | Drilling, sawing, milling, K-wire insertion, craniotomy |
| Design Features | Ergonomic design, stable output, quick-change attachment system |
| Attachment | Intended Function | Speed / Frequency | Stroke | Clamping Range / Tool Size |
|---|---|---|---|---|
| Slow Drill Assembly | Low-speed, high-torque drilling | 0–290 times/min | — | 0.8–8.0 mm |
| Hollow Drill Assembly | Cannulated drilling over guide wire | 0–800 times/min | — | 0.8–4.2 mm |
| Swing Saw Assembly | Oscillating bone cutting | 0–16,700 times/min | — | — |
| Reciprocating Saw Assembly | Reciprocating bone cutting | 0–11,000 times/min | 4.2 mm | — |
| Sternum Saw Assembly | Sternum cutting | 0–11,000 times/min | 4.2 mm | — |
| Craniotomy Drill Assembly | Cranial drilling | 0–8,000 times/min | — | 6–12 mm |
| Craniotomy Milling Assembly | Cranial milling | 0–37,000 times/min | — | 3 mm milling cutter |
| Kirschner Wire Assembly | K-wire insertion | 0–1,200 times/min | — | 0.8–1.8 / 1.5–2.5 / 2.0–3.2 mm |
